Resetting the Fiat Egea Oil Service Light and Using Launch 919X BT Diagnostic Tool with 12+8 SGM Bypass Module

Fiat Egea, Doblo, and Fiorino are widely used vehicle models in our country, known for their regular maintenance requirements. For 2018 and newer models, due to the Security Gateway Module (SGM), connecting diagnostic tools can be challenging. The oil service light serves as a reminder for timely maintenance. However, resetting this light can sometimes be complex. In this article, we will detail how to reset the oil service light on a Fiat Egea and how to use the Launch 919X BT Diagnostic Tool along with the 12+8 SGM Bypass Module during this process.

Steps to Reset the Oil Service Light on Fiat Egea, Doblo, and Fiorino

Preparation of the 12+8 Fiat SGM Cable

Access the SGM Module

  • First, remove the cables from the SGM module located under the steering wheel of the vehicle.
  • Carefully remove the 12-pin and 8-pin cables from the module.
  • Then, connect the 12+8 Fiat SGM Bypass Module to these cables. This step ensures a proper connection to the vehicle’s ECU, allowing access to the electronic systems.

Connecting the Launch 919X BT Diagnostic Tool:

Connect the Tool:

  • Attach the Launch 919X BT Diagnostic Tool to the OBD2 port located at the other end of the Fiat SGM cable.
  • Activate the device to gain access to your vehicle’s system.

Accessing the Service Menu on the Device

Enter the Service Menu

  • From the menu on your Launch 919X BT device, go to the "Service" section.
  • Locate and enter the "Oil Service Reset" or a similar option.

Resetting the Oil Service Light

Follow On-Screen Instructions:

  • Follow the on-screen instructions to complete the oil service light reset.
  • Once the process is completed, the oil service light on the vehicle will turn off and remain off until the next scheduled maintenance.
  • Advantages of the 12+8 SGM Bypass Module and Launch 919X BT Diagnostic Tool

12+8 SGM Bypass Module

Accessing the ECU system in newer vehicles like the Fiat Egea can sometimes be challenging. The 12+8 SGM Bypass Module eliminates this issue, providing easy and secure access to the vehicle's system. This module is especially beneficial for performing advanced diagnostics and maintenance procedures.

Launch 919X BT Diagnostic Tool

The Launch 919X BT stands out with its wide range of features and user-friendly interface. It offers wireless operation through Bluetooth, providing quick access to vehicle systems. In addition to resetting the oil service light, it supports detailed fault code reading, live data monitoring, and special functions.

These tools enable faster and more professional maintenance procedures for Fiat Egea, Doblo, and Fiorino vehicles. When used together with the 12+8 SGM Bypass Module, accessing the vehicle’s electronic systems and completing tasks securely is possible.

Resetting the oil service light on a Fiat Egea is a crucial task for vehicle owners. By using the 12+8 SGM Bypass Module and the Launch 919X BT Diagnostic Tool, you can perform this task professionally, ensuring the best maintenance for your vehicle. These tools not only simplify maintenance tasks but also facilitate fault diagnosis and other maintenance operations, saving time and money.

Whether you prefer to do your vehicle maintenance yourself or run a service business, these professional tools will make your tasks much easier and faster. With the right tools and methods, vehicle maintenance becomes simpler and more effective.
